The LT20 Sawmill Series presents ideal solutions for start-up wood businesses, workshops, individual estates and larger business operations that require an efficient, flexible and productive sawmill but do not need the larger volume capability of the LT40 and LT70 Series.
The LT20 cuts logs up to 80 cm in diameter and 4.8-8.4 m long. Log handling with the LT20 can be configured for the exact needs of your business – Manual or hydraulic log handling configurations are available to match productivity and budget requirements. The LT20 sawmill head retains the same productivity features of Wood-Mizer’s premium range. With the standard electronic SW Setworks, simply select the board thickness required and the head height automatically positions for each cut - no waiting for manual calculations. Forward and reverse movement is made by the adjustable power feed.
A water tank feeds lubrication directly to the blade to improve cutting performance and keep the blade clean. The electric blade guide arm keeps the blade supported while cutting various sized material. Blade tension is easily adjusted, and keeps the blade at the proper tension for cutting.
Popular Options
Full mobility for your sawmill can be achieved with the addition of a trailer package. The optional Debarker prolongs blade life by clearing away dirt and rocks from the bark. Petrol and diesel engine options available.
Sawmill LT20
Pemrosesan kayu serbaguna dan handal untuk usaha kecil
sawmill yang ideal untuk bisnis yang membutuhkan efisiensi, fleksibilitas dan produktivitas dengan harga murah.
Keunggulan:
kontrol kepala gergaji dgn motor
Tipe Stationary atau mobile
Elektronik setwork meningkatkan Produktivitas
opsi menyesuaikan Panjang Tempat Tidur & Opsi Penanganan Log
| Power | |
|---|---|
| Power | 11 kW (E15) Listrik 15 kW (E20) Listrik 25 HP Bensin 22 HP Solar |
| Kapasitas potong | |
| diameter kayu maksimum | 80 cm |
| Max. Log Length | 6.1 m (M Bed) 8.4 m (L Bed) |
| lebar kayu maksimum potong | 65 cm |
| lebar kayu maksimum | 58 cm |
| kedalaman potong maksimum | 25 cm |
| Head Features dan opsi | |
| Setworks | SW10 (for AC models) |
| Head Naik/Turun | Elektrik |
| Head Maju mundur | Elektrik |
| Blade Guide Arm | Elektrik |
| Lubrikasi Gergaji | Valve electro |
| Sistem Blade Tension | sekrup dengan meteran pengukur |
| Blade Guides Style | Rollers |
| Debarker | opsional |
| Diameter Port Sawdust Collection | 101.6mm |
| Opsi Tambahan | station operasi dari jauh (curtain) |
| Operator Location | Walk Along Wireless Remote (RM) |
| Gergaji | |
| Panjang | 4010 mm |
| Lebar | 32 mm 35 mm |
| Ketebalan | 1.00 mm 1.07 mm |
| Roda gergaji | |
| Diameter Roda Gergaji | 483 mm |
| Tipe Roda Gergaji | Belted |
| Material Roda Gergaji | Cast Iron |
| Bed Features dan opsi | |
| Konstruksi Bed | Monorail |
| Angled Bed Rails | Standard |
| Stainless Steel Rail Covers | Optional |
| Bed Extensions | Bed Extension: 0.5 m Bed Extension: 0.9 m Bed Extension manual or hidraulic : 1.8 m, 3.6 m or 7.2 m |
| Feature bed | Adjustable Legs |
| handling log | |
| Manual | Toeboards Side Support Clamp Winch Log Turner Log Loader (pompa manual) |
| STANDARD Hydraulic | 3 Side Supports Central Clamp on Two Rods Claw Log Turner Log Leveling Rollers Hold-down Clamps Log Loader |
| STANDARD Hydraulic | AH3 - M Bed AH5 - M Bed AH7 - M Bed AH14 - L Bed AH15 - L Bed |
| STANDARD PLUS Hydraulic | AHP3 - M Bed AHP5 - M Bed AHP7 - M Bed |
| SUPER Hydraulic | Chain Turner 2 Vertical Side Support Central Clamp on Two Rods Log Leveling Roller Power Roller with Two Cylinders Hold-Down Clamps Log Loader |
| Sawmill features dan opsi | |
| Konstruksi Frame | Cantilever |
| standar keamanan | CE |
| Tambahan | Cant Hook Log Deck |
